Setup
Operating Instructions 581 - 00.0 - 02/2015 79
Abb. 50: Connecting the controller
3. Connect all plugs with the connections.
4. To ensure that the cables are not accidentally pulled out
or
damaged, screw the protective bar under the table plate.
5. In addition, screw the protective bar securely to the controller.
(3) - Cable (4) - Connection
③
④
