Setup
Operating Instructions 581 - 00.0 - 02/201578
Abb. 49: Fitting the controller
2. Connect all plugs with the relevant connections. The plugs
are clearly labeled by means of identification on the cable (3)
and the connections (4) on the housing are labeled corre-
spondingly.
The cable and connection have the same designation or the
same symbol.
(1) - Screws (2) - Screws
①
②
