Setup
Operating Instructions 581 - 00.0 - 02/201572
Abb. 42: Removing the transport lock of the machine upper section
3. Remove the screws (2).
The screws prevent the clamping plates from falling out.
Abb. 43: Removing the transport lock of the clamping plates
4. Remove the screw (3).
(1) - Screw
(2) - Screws
