Setup
Operating Instructions 581 - 00.0 - 02/2015 71
7Setup
7.1 Checking the scope of delivery
The scope of delivery depends on your specific order. Upon receipt
check that the scope of delivery is correct.
7.2 Removing the transport locks
All transport locks must be removed prior to setup.
To remove the transport locks:
Step
1. Remove the lashing straps and wooden blocks from the
• Machine head
• Machine table
• Frame
2. Remove the screw (1) on the oil pan under the table plate.
The screw prevents the machine head from swiveling up
during transportation.
WARNING
Risk of cutting from cutting parts!
Severe injuries possible.
The machine may only be set up by qualified
specialists.
Wear safety shoes and gloves.
