Maintenance
Operating Instructions 581 - 00.0 - 02/2015 65
6.4 Changing the cutting blocks and blade
Depending on the area of application, you must change the cutting
blocks and blade after 6
months at the earliest. You can change
the cutting length by changing the cutting blocks. The method for
changing the cutting blocks and/or the blade differs depending
on
the sub-classes.
6.4.1 Sub-class without multiflex
Changing the cutting block
Step
1. Loosen the screw (1) (hex key in the accessory pack).
2. Pull the cutting block (2) forward and remove.
3. Insert the new cutting block and push to the end stop.
4. Retighten the screw (1).
WARNING
Risk of puncture wounds from sharp objects!
Severe injuries possible.
Only change the cutting block or blade when the
machine is switched off.
