Maintenance
Operating Instructions 581 - 00.0 - 02/2015 61
Oil
Step
1. Check the oil level in the oil reservoirs daily ( 7.16 Topping
up the oil, S. 87).
Use only DA 10 lubricant or an equivalent oil conforming to the
following specifications to top up the oil reservoirs:
• Viscosity at 40 °C: 10 mm²/s
• Flash point: 150 °C
You can obtain the oil from our sales offices under the following
part numbers:
Pneumatic system
Step
1. Check the water level in the pressure controller daily.
The water level must not rise to the level of the filter
element
(1).
ATTENTION
Risk of environmental damage from oil!
Oil is a pollutant and must not enter the
wastewater system or the ground.
Collect waste oil carefully.
Dispose of waste oil and oily machine parts
in accordance with the applicable statutory
regulations.
Container Part no.
250 ml 9047 000011
1 l 9047 000012
2 l 9047 000013
5 l 9047 000014
