Maintenance
Operating Instructions 581 - 00.0 - 02/201560
Overview of works to be performed
6.1 Inspection
Work to be performed Operating hours
8 40 160 500
Machine
Remove lint accumulations
Clean sewing dust from the area under the
throat plate
Check the oil level
Check and clean the toothed belt
Lubricate the cutting punch
Lubricate the clamping arm at the felt
Lubricate the felt at the cam plate
Pneumatic system
Check the water level in the pressure control-
ler
Clean filter element in the maintenance unit
Check the leak tightness of the system
NOTICE
Material damage due to contamination!
Sewing dust and thread residue can damage the machine.
Clean the machine as described here.
