Maintenance
Operating Instructions 581 - 00.0 - 02/2015 59
6 Maintenance
This chapter describes simple maintenance work that needs to be
carried out on a regular basis, in order to extend the service life
of the machine and achieve the desired seam quality. The main
-
tenance work can be carried out by the operating personnel.
Advanced maintenance work must only be carried out by qualified
specialists ( Service Instructions).
WARNING
Risk of puncture wounds from sharp objects!
Severe injuries possible.
Only perform maintenance work when the
machine is switched off.
WARNING
Risk of crushing from moving parts!
Severe injuries possible.
Only perform maintenance work when the
machine is switched off.
