Operation
Operating Instructions 581 - 00.0 - 02/201556
To interrupt the sewing process:
Step
1. Press push button 1.
To continue the sewing process:
Step
1. Press push button 2.
5.12.2 Sewing with the foot pedal
The foot pedal ( 2.3 Additional equipment, p. 14) is a 2-step
pedal without backpedal function:
• When the first step is pressed, the clamps are closed. To re-
open the clamps, release the first step.
• When the second step is pressed, the sewing process starts.
When the sewing process is running, you can release the
foot
pedal.
The foot pedal supports quick switch-off during sewing. You can-
not continue the sewing process with the foot pedal.
Activate quick switch-off as follows:
Step
1. Press the foot switch.
The sewing process stops.
You now have the following options:
• Interrupt the sewing process
• Continue the sewing process
