Operation
Operating Instructions 581 - 00.0 - 02/2015 47
5.8 Threading the gimp thread
Step
1. Thread the gimp thread (1) as shown in the figures (depending
on the sub-class).
For sub-classes 141 and 341, thread the gimp thread
as shown in A.
Fig. 23: Threading the gimp thread (1)
WARNING
Risk of puncture wounds from sharp objects!
Severe injuries possible.
Thread the gimp thread only when the
machine
is switched off or in threading mode.
(1) - Gimp thread
①
