5.6 Threading the needle thread
Step
1. Thread the needle thread as shown in the figures.
Fig. 16: Threading the needle thread (1)
WARNING
Risk of puncture wounds from sharp objects!
Severe injuries possible.
Only thread the needle thread when the machine
is switched off or in threading mode.
(1) - Unwinding bracket
①
