Operation
Operating Instructions 581 - 00.0 - 02/2015 41
To do this, you may have to swivel the machine up and down
a little.
4. Do not let go of the machine until the locking bolt (1)
has engaged.
Once you have completed the activities you have planned, swivel
the machine back down again.
Swiveling the sewing machine down
Step
1. Hold the machine firmly.
2. Pull out the locking bolt (1).
3. Swivel the machine down slowly.
WARNING
Risk of crushing from moving parts!
When swiveling down, the machine can
unintentionally move faster than intended and
cause serious injuries.
Hold the machine firmly when swiveling it down.
NOTICE
Damage due to machine operation when it is swiveled up!
Operating the machine when it is swiveled up can result
in
material damage.
Always swivel the machine down before starting to sew.
