Operation
Operating Instructions 581 - 00.0 - 02/201534
Fig. 10: Display after switching on
The machine moves into the insertion position and is ready
to sew, when the main menu (
4.2 Software description,
p. 29) appears.
Switching off the power supply
Information
The main switch is simultaneously the EMERGENCY STOP
switch. When the main switch is switched off, the machine
is
disconnected from the power supply.
Step
1. Turn the main switch (1) into position 0.
All drives and the controller are separated from the
mains
power.
The following appears on the display:
