Disposal
Operating Instructions 581 - 00.0 - 02/2015 113
10 Disposal
The machine must not be disposed of in the normal
household waste.
The machine must be disposed of in an appropriate and correct
manner according to the national regulations.
When disposing of the machine, be aware that it consists
of
a range of different materials (steel, plastic, electronic
components etc.). Observe the applicable national regulations for
disposal.
ATTENTION
Risk of environmental damage from
incorrect disposal!
Incorrect disposal of old oil can result in severe
environmental damage.
ALWAYS observe the legally prescribed
regulations for disposal.
