Software settings
Operating Instructions 581 - 00.0 - 02/2015108
11. Confirm with the key .
You can add further buttonhole programs. Start again with step 1.
8.3.1 Deleting a buttonhole at the end of a sequence
To delete a buttonhole at the end of a sequence:
Step
1. Use the keys or to select the last but one line
of the programmed buttonhole sequence.
2. Press the key .
3. Use the keys or to select the buttonhole
program 0.
4. Confirm with the key .
The selected buttonhole is deleted.
When you want to quit setting mode, press the key .
This will take you back to the user level.
8.3.2 Adding a buttonhole at the end of a sequence
To add a buttonhole at the end of a sequence:
Step
1. Use the key to select the last line of the programmed
buttonhole sequence.
2. Press the key .
