Software settings
Operating Instructions 581 - 00.0 - 02/2015106
Abb. 67: Programming sequences (1)
4. Select the desired sequential number using the
keys or .
5. Press the key .
The following appears on the display:
(1) - Position within the sequence
(2) - Buttonhole number
(3) - Number of buttonholes
②
①
③
