Operating instructions

9.2 Oil lubrication
Caution: Danger of injury !
Oil can cause skin eruption.
Avoid protracted contact with the skin.
In the event of contact, thoroughly wash the affected area.
ATTENTION !
The handling and disposal of mineral oils is subject to legal
regulations.
Deliver used oil to an authorized collecting s tation.
Protect your environment.
Take care not to spill oil.
Check regularly the oil level in both of the supply c ontainers 1 and 2.
The oil level should not drop below the mark “min” on the glass
inspection!
Fill up the oil reservoirs exclusively with lubricating oil DA-10 or an
equivalent oil with the following specification:
–
Viscosity at 40°C: 10 mm²/s
–
Ignition point: 150°C
DA-10 oil can be bought at the sales points o f DÜRKOPP ADLER AG
under the following parts numbers:
250-ml-Container: 9047 000011
1-Litre-Container: 9047 000012
2-Litre-Container: 9047 000013
5-Litre-Container: 9047 000014
Refilling oil supply c ontainers
–
Refill the oil supply containers 1 and 2 through the hole in the glass
inspection holes.
–
The oil level has to be above the “min”mark.
Do not fill the oil supply containers beyond the “max”mark.
45
1
12
