Operation Manual

needle system: 134-35
needle thickness (depending on the E no.):[Nm] 90 - 160
maximum sewing-thread thickness:
- cotton [NeB] 11/3
- synthetic sewing yarn [Nm] 11/3
- covering yarn [Nm] 11/4
maximum bobbin capacity
with synthetic sewing yarn Nm 30/3: ca. [m] 35
maximum stitch rate: 2800 per min.
maximum stitch length:
- forwards: [mm] 9
- backwards: [mm] 9
maximum sewing-foot stroke: [mm] 6
feeder stroke: [mm] 0.5
(above needle plate)
maximum clearance under sewing feet:
- when sewing [mm] 10
- when raised [mm] 16
Operating pressure: [bar] 6
(when equipped with RAP 13-4)
rated voltage: 3 x 400 V, 50 Hz
3 x 230 V, 50 / 60 Hz
1 x 230 V, 50 / 60 Hz
dimensions (H x W x D): [mm] 1570 x 500 x 1050
working height (ex works): [mm] 790
weight (upper part of machine only): ca.[kg] 56
7
