Operation Manual

3. Sub-classes
467-183080
: single-needle flat-bed double-lockstitch sewing machine with
underfeed, needle feed and alternating-foot overfeed
467-183081
: as 467-183080,
but with electromagnetic thread cutter beneath the needle plate
3.1 Optional equipment
Order no. Optional equipment
RAP 13-4 Electropneumatic seam bartacking and sewing foot lift
For sewing machines with thread trimmer (Subclass
467-183081
).
End bartack foot-operated, intermediate bartack hand-operated,
bartack suppression,
stitch-in-stitch sewing, sewing foot lift foot-operated.
WE-6 Maintenance unit
For electropneumatic optional equipment RAP 13-4.
797 3031 Pneumatic connection package
For the pneumatic connection of stands with maintenance unit
and pneumatic optional equipment. Consisting of connection
hose (length 5 m, diameter 9 mm), hose nozzles, hose clamps,
coupling socket and coupling plug.
4. Technical data
Noise:
workplace emission value
as specified by DIN 45635-48-A-1-KL2
467-183080
:
Lc = 84 dB (A)
stitch length: 7,2 mm
sewing-foot stroke: 1.5 mm
stitch rate: 2800 per min.
Sewing material: G1 DIN 23328 4-layer
Lc = 85 dB (A)
stitch length: 7.2 mm
sewing-foot stroke: 5.0 mm
stitch rate: 2000 per min.
Sewing material: 2-ply Skai 1.6 mm 900 g/m
2
DIN 53352
467-183081
:
Lc = 84 dB (A)
stitch length: 7,2 mm
sewing-foot stroke: 1.5 mm
stitch rate: 2800 per min.
Sewing material: G1 DIN 23328 4-layer
Lc = 85 dB (A)
stitch length: 7.2 mm
sewing-foot stroke: 5.0 mm
stitch rate: 2000 per min.
Sewing material: 2-ply Skai 1.6 mm 900 g/m
2
DIN 53352
6
