Operation Manual

8.2 Lubrication
Caution - danger of injury
Oil can cause skin eruptions.
Avoid protracted contact with the skin.
In the event of contact, thoroughly wash the affected area.
IMPORTANT
The handling and disposal of mineral oils is subject to legal
regulation.
Deliver used oil to an authorised collection point.
Protect your environment.
Take care not to spill oil.
To lubricate the special sewing machine use only
ESSO SP-NK 10
lubricating oil or an
equivalent oil of the following specification:
–
viscosity at 40° C : 10 mm
2
/s
–
flashpoint: 150 °C
ESSO SP-NK 10
is available from
DÜRKOPP-ADLER AG
retail outlets under the
following part numbers:
2-litre container: 9047 000013
5-litre container: 9047 000014
maintenance work explanation operating
to be carried out hours
- Lubricate the upper part of
the machine.
- Fill tube 1 to the brim with oil.
The oil slowly reaches the upper part
of the machine through the felt beneath
the tube.
8
- Lubricate the shuttle. - Remove knee lever.
- Turn the upper part of the machine over.
- Fill tube 4 with oil up to the "
max.
"
mark.
8
- Lubricate the lower part
of the machine.
- Unscrew oil-filler cap 2.
- Top up with oil.
- Check oil level at sight glass 3.
The oil level must be between the
upper red line and the "
LEER
" [] line.
- Replace oil-filler cap.
- Remove any oil which has overflowed
into the oil collector.
40
27
