Physical
Unit Dimensions
Pd-TX-1000 5.50”L x 3.13”W x 2.52”D
Pd-TX-2000 5.50”L x 3.13”W x 2.52”D
Environmental
Operational Temp -10 degrees C to 70 degrees C
Power
Input Voltage 11 to 18 VDC
Power Consumption
Pd-TX-1000 Fully Operational ~ 24 Watts typical
Pd-TX-2000 Fully Operational ~ 30 Watts typical
Control
PC Control Interface RS-232.
Memory Eight user-programmable configurations
Video Encoding
Compression Standard MPEG-2 with non-DVB modes
Chrominance Profile 4:2:0
Line Standard PAL 625 or NTSC 525
Horizontal Resolution 704, 528, 480, 352 pixels (528 as standard)
Vertical Resolution 576 (625 lines) or 480 (525 lines)
Video Bitrates 1Mbps to 10 Mbps
System Latency End to end delay of 43 milliseconds
SPECIFICATIONS
