GigMAC PMC and PCI Board and Driver Users Manual
Pn3/Jn3 32 Bit PCI
1 NC PCI-RSVD GND 2
3 GND C/BE[7]# 4
5 C/BE[6]# C/BE[5]# 6
7 C/BE[4]# GND 8
9 NC VIO PAR64 10
11 AD[63] AD[62] 12
13 AD[61] GND 14
15 GND AD[60] 16
17 AD[59] AD[58] 18
19 AD[57] GND 20
21 NC VIO AD[56] 22
23 AD[55] AD[54] 24
25 AD[53] GND 26
27 GND AD[52] 28
29 AD[51] AD[50] 30
31 AD[49] GND 32
33 GND AD[48] 34
35 AD[47] AD[46] 36
37 AD[45] GND 38
39 NC VIO AD[44] 40
41 AD[43] AD[42] 42
43 AD[41] GND 44
45 GND AD[40] 46
47 AD[39] AD[38] 48
49 AD[37] GND 50
51 GND AD[36] 52
53 AD[35] AD[34] 54
55 AD[33] GND 56
57 NC VIO AD[32] 58
59 NC PCI-RSVD PCI-RSVD 60
61 NC PCI-RSVD GND 62
63 GND PCI-RSVD NC 64
