GigMAC PMC and PCI Board and Driver Users Manual
Pn2/Jn2 32 Bit PCI
1 NC +12V TRST# 2
3 TMS TDO 4
5 TDI GND 6
7 GND PCI-RSVD NC 8
9 NC PCI-RSVD PCI-RSVD NC 10
11 NC BUSMODE2# +3.3V 12
13 RST# BUSMODE3# PMC_1 14
15 3.3V BUSMODE4# NC 16
17 NC PCI-RSVD GND 18
19 AD[30] AD[29] 20
21 GND AD[26] 22
23 AD[24] 3.3V 24
25 IDSEL AD[23] 26
27 +3.3V AD[20] 28
29 AD[18] GND 30
31 AD[16] C/BE[2]# 32
33 GND PMC-RSVD NC 34
35 TRDY# +3.3V 36
37 GND STOP# 38
39 PERR# GND 40
41 +3.3V SERR# 42
43 C/BE[1]# GND 44
45 AD[14] AD[13] 46
47 M66EN AD[10] 48
49 AD[08] 3.3V 50
51 AD[07] PMC-RSVD NC 52
53 +3.3V PMC-RSVD NC 54
55 NC PMC-RSVD GND 56
57 NC PMC-RSVD PMC-RSVD NC 58
59 GND PMC-RSVD NC 60
61 ACK64# +3.3V 62
63 GND PMC-RSVD NC 64
