GigMAC PMC and PCI Board and Driver Users Manual
6.3 PMC CONNECTOR PIN/SIGNAL DEFINITIONS
PMC Connectors Pin Assignments
Pn1/Jn1 32 Bit PCI
1 TCK -12V NC 2
3 GND INITA# 4
5 INTB# INTC# NC 6
7 BUSMODE1# +5V 8
9 NC INTD# PCI-RSVD NC 10
11 GND PCI-RSVD NC 12
13 CLK GND 14
15 GND GNT# 16
17 REQ# +5V 18
19 VIO AD[31] 20
21 AD[28] AD[27] 22
23 AD[25] GND 24
25 GND C/BE[3]# 26
27 AD[22] AD[21] 28
29 AD[19] +5V 30
31 NC VIO AD[17] 32
33 FRAME# GND 34
35 GND IRDY# 36
37 DEVSEL# +5V 38
39 GND LOCK# 40
41 NC SDONE# SBO# 42
43 PAR GND 44
45 NC VIO AD[15] 46
47 AD[12] AD[11] 48
49 AD[09] +5V 50
51 GND C/BE[0]# 52
53 AD[06] AD[05] 54
55 AD[04] GND 56
57 NC VIO AD[03] 58
59 AD[02] AD[01] 60
61 AD[00] +5V 62
63 GND REQ64# 64
