GigMAC PMC and PCI Board and Driver Users Manual
LED_ACT (activity)
LED_LINK (link)
LED_1000 (1000 Mb mode)
LED_100 (100 Mb mode)
Model 5162 dual-port PMC with RJ-45 connector(s)
The front panel has two onboard RJ-45 connectors that supports the connection
of Category 5 cabling with 4 LED indicators per port that provide the following as
marked with silkscreen nomenclature on front panels:
LED_1000 (1000 Mb mod)
LED_FD (full-duplex mode)
LED_TX (transmit activity)
LED_RX (receive activity)
Model 5262 dual-port or 5261 single port PMC with RJ-45
connector(s)
The front panel has two onboard RJ-45 connectors that supports the connection
of Category 5 cabling with 4 LED indicators per port that provide the following as
marked with silkscreen nomenclature on front panels:
LED_1000 (1000 Mb mod)
LED_FD (full-duplex mode)
LED_TX (transmit activity)
LED_RX (receive activity)
Model 5164 quad-port PMC with RJ-45 connector(s)
The front panel has four onboard RJ-45 connectors that supports the connection
of Category 5 cabling with one bi-color LED indicators per port that provides an
“activity” indicator.
