pressure prevention
specifications
LS9500 10 " Lateral Rotation Mattress with on
Demand Low Air Loss
• The Masonair™ LS9500 Turn-Style system incorporates
the functions of lateral rotation and low air loss in one
unit.
• The user friendly high flow control unit oers 10
comfort levels, adjustable turning cycles and maximum
turn angle adjustment of up to 40 degrees.
• The continuous feedback sensor technology of the
control unit will equalize pressure and maximize patient
comfort.
Pump Power 110VAC / 60 Hz
Pump Airflow 45 LPM
Pump Cycle Time N/A
Pump Type Compressor
Pump Alarms Visual / Audible
Mattress Dimensions 80" x 36" x 10"
Mattress Cover Material Fluid-Resistant Nylon
Weight Capacity 500 lbs.
Warranty 1 Year
• The mattress is constructed of (20) 8” high split-air
cells over a 2" foam base with (2) 10" high side air
bolsters.
• The lateral rotation mode will assist in pulmonary
blood flow and mucosal drainage, while the “on
demand” low air loss function will provide a cool and
dry surface for prevention and treatment of pressure
ulcers.
• The (2) side bolsters provide the patient with optimal
comfort while creating a safe environment during
rotation.
• 10, 20, 30 & 60 minute adjustable turning cycles.
• ¼, ½, ¾ & full position adjustable turning positions up
to 40°.
• Lockout feature to protect patient settings.
• Auto-Firm feature for max inflation when transferring
patient and has auto-recovery after 30 minutes.
• Audible and visual low pressure alarms.
• CPR deflation in 20 seconds.
Item # Product Description Product Dimensions Product HCPCS UOM
LS9500 Lateral Rotation Mattress with Low Air Loss 80" (L) x 36" (W) x 10" (H) E0277 1/ea
Perfect Turning Mattress
for Facilitating
Pulmonary Drainage
& Pressure Ooading
