Vigor2750 Series User’s Guide
192
Default Key All wireless devices must support the same WEP
encryption bit size and have the same key.
Key1-Key4 Four keys can be entered here, but only one key can be
selected at a time. The format of WEP Key is restricted to
5 ASCII characters or 10 hexadecimal values in 64-bit
encryption level, or restricted to 13 ASCII characters or 26
hexadecimal values in 128-bit encryption level. The
allowed content is the ASCII characters from 33(!) to
126(~) except '#' and ',' .
Authentication Mode Choose OPEN or SHARED as the authentication mode.
OPEN: Set wireless to authentication open mode.
SHARED: Set wireless to authentication shared mode.
z WPA-PSK
Accepts only WPA clients and the encryption key should be entered in PSK. The WPA
encrypts each frame transmitted from the radio using the key, which either PSK
(Pre-Shared Key) entered manually in this field below or automatically negotiated via
802.1x authentication.
WPA Mode Select WPA, WPA2 or Auto as the type.
