Setting Up the 708-DS / 709-DS 3
708-DS / 709-DS Operator’s Manual 23
Equipment, Parts, and Accessories As Shipped
Parts and Accessories
Locate the following items, as applicable, for your system
configuration:
Agilent 708-DS / 709-DS Dissolution Apparatus Alignment Posts or Evaporation Plugs
Heater / Circulator (708-DS) Evaporation Covers
DVH Power Controller (709-DS) Evaporation Cover Plugs
6-pin Cable for Heater / Circulator (708-DS) TruAlign Blank Vessel Position Covers
DVH Power Controller Communication Cable (709-DS) 3-Fin Baskets (709-DS)
Bath Temperature Probe (708-DS) Thermal Printer Paper
External Vessel Temperature Probe (optional) 17-mm Open-end Wrench
Power Cord(s) 90 º Allen Key (for Level Adjustment)
Manifold Arm Labels Shaft Locking Collars
6-pin Cable for Heater / Circulator Vessel Centering Tool
Bath Temperature Probe Thermal Printer Paper
Rinse Cups (or Tray) 7/64" T-handle Allen Wrench
Dissolution Vessels Stainless Steel Tubing Clamps (708-DS)
Alignment Posts Plastic Tubing - 1/2" outer diameter (708-DS)
DDM Assemblies 25-mm Height Spheres
Basket Shaft Assemblies Clip-on Basket Height Gauge
Paddle Shaft Assemblies Bubble Level
Technical Documentation CD
