G420F(FE) Service Manual Chapter 6. LPG FUEL DELIVERY SYSTEM 230
Parts Description
CA100 Mixer for G420F Engine
Refer to Figure 45 exploded view on facing page.
REF NO. DESCRIPTION QTY
1 Screws 10-24 x 5/8” SEMS 4
2 Mixer Cover 1
3 Air Valve Spring 1
4 Screws 6-32 x 1/4” SEMS 5
5 Plate Backup 1
6 Diaphragm, Silicone 1
7 Air Valve Ring 1
8 Air Valve Assembly 1
9 Idle Screw 3/8-16 x 1-1/4” 1
10 Idle Screw Spring 1
11 Plugs, 1/8” Pipe Hex Head 2
12 Mixer Body Assembly 1
13 Screws, 1/4-28 x 5/16” 2
14 Plug, 1/4” Pipe 1
15 Screws 10-24 x 5/8” SEMS 4
16 Air Horn 1
17 Air Horn Gasket 1
18 Throttle Body to Mixer Gasket 1
Parts List for CA100 Mixer
