G420F(FE) Service Manual Chapter 6. LPG FUEL DELIVERY SYSTEM 218
N-2007 Regulator for G420FE Engine
Parts List of N-2007 Regulator (Certified)
REF NO DESCRIPTION QTY
1 N-2007 Body 1
2 Diaphragm, Primary Assembly 1
3 Springs, Primary Assembly 2
4 Cover, Primary Assembly 1
5 Spring, Secondary Seat, Red 1
6 Dowel Pin Ø 0.094” x 1” L (Ø 2.39mm x 25.4mm L) Hardened Steel 1
7 Diaphragm, Secondary Assembly 1
8 Lever, Secondary 1
9 Seat, Secondary 1
10 Valve Primary 1
11 Fillister Head Screws SEMS Split Lockwasher #12-24 x 5/8” 6
12 Pan Head Screw SEMS Ext. Tooth Lockwasher #12-24 x 1/4” 1
13 Body Gasket 1
14 Back Plate 1
15 O-ring, Size 107 GLT Viton® 1
16 Bottom Plate Gasket 1
17 Plate Cover 1
18 Fillister Head Screws SEMS Split Lockwasher #12-24 x 1-3/8” 6
19 Hex Head Screws SEMS Split Lockwasher 1/4-20 x 5/8” 4
20 Plug, Socket Head Pipe (T-086) 1
21 Cover, Secondary Diaphragm 1
22 Lockwasher, Int. Tooth (T-210) #8 SST 6
23 Torx Screws (T-15) #8-32 x 5/8” 6
