G420F(FE) Service Manual Chapter 5. Engine Management System (EMS) 151
Q’ty
Components
G420FE G420F
Items Specifications
Ground speed limit
switch
option option
Type
Actuation Pressure
Normal Open
145 ± 28 kPa
Electronic Throttle System
Q’ty
Components
G420FE G420F
Items Specifications
Electronic Throttle
System 1 1
Minimum Electrical
Resistance of Throttle
Actuator
1.5 ohms
Ignition System Components Specification
Q’ty
Components
G420FE G420F
Items Specifications
Power TR 4 4 Operating Voltage 5-16V
Ignition Coil Ass’y
4 4
Coil Type
Coil Supply Voltage
Primary Resistance
Inductive
8-16 Vdc
0.71 ohm +/- 9%
Spark Plug
4 4
Material
Air Gap
Platinum spark plug
0.7-0.8 mm
