G420F(FE) Service Manual Chapter 1. General Information 14
General Specification
G420FE Engine G420F Engine
LP FUEL SYSTEM
LP FUEL SYSTEM
Closed loop LP Carburetion
System
Open loop LP Carburetion System
MIXER:
Diaphragm Type Air Valve
Assembly inside, Downdraft
(Model: CA-100)
Diaphragm Type Air Valve
Assembly inside, Downdraft
(Model: CA-100)
REGULATOR:
Two-Stage Negative Pressure
Regulator (Model: N-2007)
Two-Stage Negative Pressure
Regulator (Model: N-2001)
FUEL TRIM VALVE (FTV): Dual Dither System No FTV
FUEL FILTRATION: 40 Microns Maximum 40 Microns Maximum
GASOLINE FUEL SYSTEM
GASOLINE FUEL SYSTEM Closed loop MPI System and In-Tank Fuel Pump System
FUEL PUMP MODULE Electric Fuel Pump (12V)
Fuel Filter & Strainer
Gasoline Pressure Regulator (3.5 bar)
FUEL INJECTOR ASS’Y Electric Fuel Injector (12V)
ENGINE ELECTRIC
ENGINE CONTROL
MODULE(ECM):
12 V operation volt, 48 pins of I/O
CRANK SENSOR Magnetic Inductive type
CAM SENSOR Hall sensor
TMAP: Intake Air Temp. & Manifold Absolute Press. Sensor
PEDAL ANGLE SENSOR: Two-Output Signals (built in Accelerator Pedal)
Gasoline : One Oxygen sensor
OXYGEN SENSOR: Dual Oxygen Sensor System
LPG: No Oxygen sensor
ECT-ECM: Engine Coolant Temperature Sensor for ECM
ECT-GAUGE Engine Coolant Temp. Sensor for GAUGE on Instrument Panel
TPS: Throttle Position Sensor (built in Throttle Body)
THROTTLE BODY: Electronic Throttle Body
LP FUEL LOCK-OFF: 12 V operation volt
ENGINE OIL PR. S/W: 28.4 kPa (4.1 psi)
STARTING MOTOR: 12 Volts, 1.7 kW
ALTERNATOR: 13.5 Volts, 90 Amp
EXHAUST SYSTEM
Muffler Catalytic Muffler Muffler (without catalyst)
