User's Manual

2
Chapter II Basic Operation
2.1 Appearance
1 Power key Power on/off the device.
2 Dial shortcut key Press on it to enter the Dial interface to make calls
3 SIM card slot Insert the SIM card.
4
Microphone For voice input
5 Earphone Jack Connect with the stereo earphone, 3.5mm
6
T-FLASH card
slot
Inserted with a T-FLASH card containing map
software, map data and user documents. Do not
remove it while operating the device. Reset the device
when the card is pulled out improperly.
7 USB port
Connect and communicate with computer through a
MINI USB cable and is used as the charging port.
8 LCD indicator
The indicator is red while the device is being charged
and turns green when it is fully charged.
