User's Manual

A7
User Manual
Product Diagram
Specification
Wireless version: V5.0
Input: Micro USB DC 5V1A
Charging: 500mAh
Bluetooth distance: >15M
Charging time: about 2 hours
Speaker power: 3W3Ω
Product size: 70*76.5*25.6mm
Bluetooth Speaker
Attention Please
Can NOT paired
Please ensure the speaker is ON, and the Blue LED is in quicky flash,
speaker is in Pairing. Speaker can only paired with one device in one time,
to check if it already paired with another device. Otherwise you have to turn
on the speaker and try once again. Transmission range is about 8-10M,make
sure your phone is not far away from speaker.
Speaker OFF automatically
Speaker powered off if no operation in 10min when the speaker is well
paired.You have to reset the speaker.
1.Please stock it in normal temperature.
2.Please don’t use under the high humidity and temperature for long time.
3.Please don’t place it together with Magnetized materials.
4.High-altitude falling may destory the speaker.
5.Please don’t try to tear the speaker by yourself, or cleaning it with chemical
solvent
6.Please turn off the speaker if long time not to use.
Packing List
Speaker*1pc, User Manual*1pc, USB charging*1pc, Carabiner*1pc
Operation Instruction
1. Press the power button about 5sec, Speaker will be ON with blinking Blue
indicator and voice announced
(Speaker will be automatically in Bluetooth Mode if unplug the Aux in Cord.)
2. The speaker will be automatically switched to Aux in mode when plugged in
Aux in cord.
1. Speaker will automatically paired with last device. Quick flash Blue Led
indicated the speaker is in pairing. (The pairing time will be different from
different device)
1).
Bluetooth Connection
1. The speaker will switch to Aux In mode when plugged in Aux in Cord, the
Blue LED in slow flash.
2. Connected the speaker with computer/smartphone via Aux in Cord.
2).
Aux In Mode
2.Turning on the BLUETOOTH on your smartphone setting, and searching
for the “A7”and paired with voice announced, the Blue LED flash in slow
flash after well paired.
3. Playing music wireless after well paired.
4. Answering and ending a call works the same way: simply click the
PLAY/PAUSE button on your speaker unit.(Some smartphone automatically
using bluetooth calling if answering calls on the phone.)
Long press the button “+/-”to up & down the volume.
3).
Volume UP & Down
FAQ
Sound Quality
Intermittent failure of sound or speaker automatically powered off, please
charge the speaker now. Speaker will be slightly virbrated with stronger
bass, please clean the pad now. the pad is used for more bass and better
sound. Please ensure the protection of the pad is moved in the using
process.
Click the button “+/-”to switch previous & next songs.(in Bluetooth Mode)
4).
Previous & Next Songs switch
7). Instruction for LED Indicator
5). Method of connecting with computer/tablet
6). How to Charging
Please ensure you have Bluetooth program on your device, then pairing
the bluetooth the same way as smartphone stated above.
Charging by Micro USB cord. The RED indicator keeps light in charging,
lights turned off when fully charged.Red indicator flash when speaker is
in low battery. The charging time is about 2H.
Quick Flash in BLUE is in pairing,flash slow indicated well paired. LED
becomes RED in Aux in mode. When charging, LED is in solid RED, LED
light turned off when fully charged, if low battery, flashing in RED
Size: 320*66mm
材质：80g书纸+双面单色印刷+风琴折2折
USB Charging Slot
Aux In Slot
Play/Pause/Calling
Power
MIC
Volume Up/Previous
Volume Down/Next
Bluetooth Indicator
