Datasheet

07/06/2007 V10.0

DDP-SJS-MN2-1

• DDP-SJS-M1

• DDP-SJS-M2

• DDP-SJS-N1

• DDP-SJS-N2

AllnGap

Pure Green, 560nm

120

18.0 - 45.0

18.0 - 22.4

22.4 - 28.5

28.5 - 35.5

35.5 - 45.0

NOTE

1. All part number above comes in a quantity of 2000 units per reel.

2. Other luminous intensity groups are also available upon request.

3. Luminous intensity is measured with an accuracy of ± 11%.

4. Wavelength binning is carried for all units as per the wavelength-binning table. Only one wavelength group is allowed for each reel.

5. An optional Vf binning is also available upon request. Binning scheme is as per following table.

Part Ordering

Number

Chip Technology

/ Color

Viewing

Angle˚

Luminous Intensity @

IF = 20mA IV (mcd)

AllnGap : DDx-xJS

DOMINANT
