Datasheet

07/06/2007 V10.0
14
Recommended Sn-Pb IR-Reow Soldering Prole
275
250
225
200
175
150
125
100
75
50
25
0 50 100 150 200
183˚C
Ramp-up
3˚C/sec max.
235-240˚C
10-30s
60-150s
Ramp-
down
6˚C/sec
max.
Preheat 60-120s
360s max
Time (sec)
Temperature (˚C)
Classication Reow Prole (JEDEC J-STD-020C)
0 50 100 150 200
300
250
225
200
175
150
125
100
75
50
25
275
Temperature (˚C)
Classication Reow Prole (JEDEC J-STD-020C)
Ramp-up
3˚C/sec max.
255-260˚C
10-30s
60-150s
Ramp-
down
6˚C/sec
max.
Preheat 60-180s
480s max
217˚C
Recommended Pb-free Soldering Prole
AllnGap : DDx-xJS
DOMINANT
TM
Semiconductors
Innovating Illumination
