Technical description FanTastic Vent
16
5 Technical description
5.1 Components
6 Instructions before installation
➤ Before installation, check the roof thickness of your vehicle. Consult the vehicle
manufacturer if you have any questions.
➤ When choosing the installation location, observe the following:
– Select the installation location so that it is as near to a 12 V connection as
possible.
– Adjoining components (roof rack or attachment and reinforcing parts), cables
and cabinets in the vehicle interior must not get damaged when sawing the
hole.
– Only fit the roof light on flat and parallel interior and exterior roof areas with a
maximum inclination of 15° to the horizontal.
You may use an existing roof hole provided the roof light fits into it.
No. in
fig. 1,
page 3
Description
1Cover hood
2 Top grille ring
3 Fan blades
4 Fan blade screw
5 Fan base
6 Grille assembly
7 Hoist motor assembly
8 Bottom grille ring
