Installing the toilet Saneo B, Saneo C
26
4.6 Installing the tank flap
➤ Use the tank flap when using the models Saneo BW and CW Saneo with
integrated water tank.
➤ For installing the tank flap, use the template (1), item 5.3.1 on page 163,
to make the cutout in the wall.
➤ Provide a sealant (butyl rubber) between the vehicle outer wall and the
tank flap.
➤ Then place the tank flap on the tank and secure the tank flap with bolts.
➤ Use grease to lubricate the O-ring in order to prevent difficulties when
connecting the filler neck to the upper part of the tank.
The tank flap is bolted with four countersunk screws (C4x25) (not included).
Item Description
1 Position of the O-ring with a wall thickness of 30 mm – 50 mm
2 Position of the O-ring with a wall thickness of 20.5 mm – 30 mm
1
2
