Operating instructions

MCA1215, MCA1225, MCA1235 Technical data

Output data

Dimensions and weight:

Technical data MCA-RC1 (accessory)

MCA1215 MCA1225 MCA1235

Charging voltage: 14.4 V / 14.7 V

Retention voltage: 13.8 V

Rated charging current: 15 A 25 A 35 A

Charging current: 0 – 15 A 0 – 25 A 0 – 35 A

Outputs: 1 2 2

ESB outputs

(Starter battery):

111

ESB charging voltage : 13.8 V 13.8 V 13.8 V

ESB charging current: 2 A 2 A 2 A

MCA1215 MCA1225 MCA1235

Ref. no.: 9108400809 9108400810 9108400811

Dimensions L x W x H (mm): 238x179x63 238x179x63 274x179x63

Weight: 1.6 kg 1.7 kg 1.9 kg

MCA-RC1

Ref. no.: 9102500037

Rated input voltage: 10.5 – 15 Vg

Standby current consumption: < 40 mA

Protection class: IP21

Maximum ambient temperature: –10 °C to +45 °C

Storage temperature: –30 °C to +70 °C
