Operating instructions

EN
Connecting the device MCA1215, MCA1225, MCA1235
18
– without; ✓ with
Charging the battery
➤ Connect the battery to the “DC OUTPUT” socket of the MCA battery charger.
Make sure the polarity of the connections is correct.
Charging the starter battery
➤ Connect the starter battery to the “ESB” socket of the MCA battery charger.
Make sure the polarity of the connections is correct.
Charging using the temperature sensor MCA-TS1 (accessory)
➤ Connect the temperature sensor to the TEMP/LIN connection.
✓ The charging voltage is adjusted according to the temperature measured.
Charging using the IBS battery sensor MCA-HS1 (accessory)
➤ Connect the battery sensor to the TEMP/LIN connection.
✓ The battery sensor transmits the battery temperature and the battery voltage to
the charger via the LIN communication port. The charging voltage is regulated
according to the temperature. Any potential loss of voltage in the connecting
cables is also compensated.
Charging using the battery management system PerfectControl MPC01
(accessory)
➤ Set the DIP switches 1 to 3 on the MCA battery charger to “ON” (chapter “Setting
the DIP switches” on page 23).
You can find detailed information in the operating manual for MPC01.
fig. 4, page 17 fig. 5, page 17
Battery sensor
MCA-HS1 (IBS)
Perfect Control
MPC01
Remote control
MCA-RC1
Temperature sensor
MCA-TS1 or
Battery sensor
MCA-HS1 (IBS)
–– ––
✓ – ✓ –
✓✓ – ✓
✓✓
