ENGLISH Ice Flow Water Flow High Pressure Low Pressure Comp Auger Ice Bin Full Power On/Off Function Dometic Eskimo Ice Crushed Ice systems OPERATION MANUAL For Self-Contained & Remote Systems Using Digital Controls (For b-16 to c-18 Software) Dometic Corporation, Marine Division Rev.
COPYRIGHT © 2007, 2008 Dometic Corporation, All Rights Reserved. No part of this publication may be reproduced, translated, stored in a retrieval system, or transmitted in any form or by any means electronic, mechanical, photocopying, recording or otherwise without prior written consent by Dometic Corporation. Every precaution has been taken in the preparation of this manual to insure its accuracy. However, Dometic Corporation assumes no responsibility for errors and omission.
Eskimo Ice Systems DOMETIC ESKIMO ICE CONTROL OPERATION MANUAL Contents INTRODUCTION 4 Operation 4 Events that can interrupt normal production 4 Programmable Parameters 5 Program Parameter Description 5 Programmable Parameter Table 6 Typical Operation Cycle Table 7 Owner's Limited warranty 10 Limited Warranty Periods 12 Dealer Locator 13 ENGLISH 3
Eskimo Ice Systems INTRODUCTION This operation manual provides information for self-contained and remote Eskimo Ice Systems using digital controls. Please refer to Eskimo Ice Manual L-2448A for installation of the self-contained system and L-2448B for installation of the remote system.
Eskimo Ice Systems H20 – Potable water switch. If the potable water switch is open during production for 15 seconds, the display will show H20 fault and the Water Flow LED will light. The auger will continue to run for the duration of the auger delay. Ice production will stop and the switch must be closed for operation to restart. H20 Fault can be caused by lack of fresh water flow, clogged main filter or a clogged Y Strainer. SPt – Auger spout blockage.
Eskimo Ice Systems t-3: CAN ID: Used to set CAN bus ID. The range is from 1-254. t-4: Group ID: Used to set CAN bus ID. The range is from 1-254. t-5: Reset Programmable Parameters: Resets all programmable parameters to factory defaults. Set this setting to 1 and unit will reset all values. Setting will change back to 0 on exit of the programming mode or by pressing the On/Off button to scroll through parameters.
Eskimo Ice Systems Typical Operation Cycle Table ACTION Delay before Next Step (in seconds) and/or description of action Initial Start Up Via Breaker 60 Pump ON 30 Auger ON 15 Assumed display is in ON position. If not, turn unit on via display. Compressor ON Will continue until sensor reads bin full for 30 sec., fault trip or unit manually shut down. Ice Production BIN FULL 30 Auger Clears Machine Shuts Down Ice removed from bin Sensor reads bin not full, calls for ice production.
Eskimo Ice Systems Figure 3.
Eskimo Ice Systems Figure 4. Location of Ice Bin Sensor Display Cut Out Dimensions 3.1875 3.1875 Figure 5.
Eskimo Ice Systems Owner's Limited warranty As hereinafter described, Dometic Corporation limits the duration of any implied warranty to the duration of the underlying express warranty and also disclaims any liability for consequential or incidental damages arising from any application, installation, use or malfunction of any warranted product.
Eskimo Ice Systems Department at (954) 973-2477, to obtain the manufacture date. The hours of the Customer Service Department are 8:00 am - 5:00 pm (USA, Eastern Time Zone) Monday through Friday excluding holidays. 2. It is possible that there might exist a considerable time lag between the date a component is manufactured and the date it is put in service. In such instances, the date of manufacture could indicate that the item is out of warranty.
Eskimo Ice Systems Limited Warranty Periods Please read and keep this document with your important paperwork. Use it as a reference in the future. If you have any questions, please contact the Dometic Corporation Service Department at (954) 973-2477 for clarification. Note: Any model or replacement part that has been installed due to a warranty failure will carry only the remainder of the original warranty. All warranties begin when the customer takes possession of the equipment.
Eskimo Ice Systems Dealer Locator AER Marine Supply Cruisair Suncoast, Inc. Ocean Options 2301 NASA Parkway Seabrook, Texas 77586 USA Contact: Richard S. Miller Phone: (281) 474-3276 (800) 767-7606 Fax: (281) 474-2714 E-mail: richard.miller@aersupply.com Web: www.aersupply.com 3301 34th Avenue North St. Petersburg, Florida 33713 USA Contact: Roy Justice Phone: 727-526-7875 Fax: 727-528-9519 E-mail: cruisairsuncoast@yahoo.
