PS120A, PS180A Using the appliance
9
6 Using the appliance
6.1 Positioning the solar panel
I
➤ Locate a clear area free from over hanging branches or obstructions.
➤ Remove the solar panel from the carry bag.
➤ Unclip the latches on the side of the unit and unfold the panel.
No. in
fig. 3
Description
1 Solar panel terminals
2 Battery terminals
3 Load terminals
NOTE
To obtain maximum output, regularly move the solar panel to track
movement of the sun throughout the day.
1 2 3
3
