Technical data PS120A, PS180A
16
11 Technical data
Controller:
PS120A PS180A
Ref. no.: 9108400883 9108400917
Panel type: Monocrystalline
Peak power: 120 W ±3% 180 W ±3%
Voltage at max. power (V
mp
): 18.1 V
Current at max. power (I
mp
): 6.63 A 9.95 A
Open circuit voltage: 22.44 V
Short circuit current: 7.09 A 10.5 A
Operating temperature: –40 °C to +85 °C
Max. system voltage: 700 V
In-line fuse: 15 A, automotive, fast acting
Net weight 12.25 kg 17 kg
Test condition: Irradiance 1000 W/m², AM = 1.5
Module temperature 25 °C
Rated current: 10 A 20 A
Rated voltage: 12 Vg
Over-charge protection: 14.4 ± 0.3 Vg
Over-discharge:
Cut-off:
Resume:
11 ± 0.3 Vg
12 ± 0.3 Vg
Over-voltage:
Cut-off:
Resume:
16.5 Vg
15.0 Vg
Voltage drop:
Between input and batteries:
Between batteries and load:
0.5 Vg
0.2 Vg
No load current draw: <5 mA
Ambient temperature: –10 °C to +55 °C
