User manual

Technical data PerfectCharge

15 Technical data

DCC1224-10 DCC1224-20

Ref. no.: 9600003748 9600003749

Transformation: 12 V  24 V

Nominal input voltage: 12 Vg

Input voltage range: 8 V – 16 V

Charging current: 10 A 20 A

Charging voltage: 26.4 V – 29.4 V

Output: 250 W 500 W

Residual ripple of output

voltage at rated current:

< 50 mV rms

Efficiency: up to 90 %

Idle power consumption: < 0.4 A

Ambient temperature for

operation:

–20°C to +50°C

Ambient humidity: 95 % Non-condensing

Dimensions (W x D x H): 153 x 73 x 220 mm 153 x 73 x 260 mm

Weight: 1.55kg 1.85kg

Inspection/certification:
