User manual

PerfectCharge Technical data

Protective devices

DCC1212-20 DCC1212-40

Ref. no.: 9600003754 9600003755

Transformation: 12 V  12 V

Nominal input voltage: 12 Vg

Input voltage range: 8 V – 16 V

Charging current: 20 A 40 A

Charging voltage: 13.2 V – 14.7 V

Output: 250 W 500 W

Residual ripple of output

voltage at rated current:

< 50 mV

eff

Efficiency up to: 90 %

Idle power consumption: < 0.4 A

Ambient temperature for

operation:

–20°C to +50°C

Ambient humidity: 95 % Non-condensing

Dimensions (W x D x H): 153 x 73 x 220 mm 153 x 73 x 260 mm

Weight: 1.55kg 1.85kg

Inspection/certification:

12 V 24 V

Input: High voltage, low voltage, reverse polarity

protection (internal fuse)

Low-voltage cut-out: 8 V 16 V

Low voltage restart: 10 V 20 V

High voltage shutdown: 16 V 32 V

High voltage restart: 15.5 V 31 V

Temperature: Shutdown

Short circuit protection: yes, I
