PerfectCharge Technical data

DCC2412-20 DCC2412-40

Ref. no.: 9600003750 9600003751

Transformation: 24 V  12 V

Nominal input voltage: 24 Vg

Input voltage range: 16 V – 32 V

Charging current: 20 A 40 A

Charging voltage: 13.2 V – 14.7 V

Output: 250 W 500 W

Residual ripple of output

voltage at rated current:

< 100 mV

eff

Efficiency up to: 90 %

Idle power consumption: < 0.4 A

Ambient temperature for

operation:

–20°C to +50°C

Ambient humidity: 95 % Non-condensing

Dimensions (W x D x H): 153 x 73 x 220 mm 153 x 73 x 260 mm

Weight: 1.55kg 1.85kg

Inspection/certification:
