Set float voltage
You can use the DIP switches S3 and S4 to set the float voltage in the U phase (float).
Set charging mode
!
You can set the charger mode using the S5 and S6 DIP switches.
S3 S4
Float voltage
12 V 24 V
ON ON 13.8 V 27.6 V
OFF ON 13.5 V 27.0 V
ON OFF
13.2 V 26.4 V
OFF OFF
WARNING! Danger of explosions!
Use only the charging mode appropriate for your battery type. If neces-
sary inquire at a specialist workshop.
S5 S6 Charger Mode
ON ON IU0U- charging
Refer to chapter “Battery charging function” on
page 16.
OFF ON Constant voltage 1
The battery charger works as a constant voltage
source, where the value of the voltage corresponds
to the set charging end voltage.
ON OFF Constant voltage 2
The battery charger works as a constant voltage
source, with the value of the voltage corresponding
to the set floating voltage.
OFF OFF
