Media Meter 2 User’s Manual
Understanding the Log and the Graph
Inbetween,theloglistsseveralattributesforeachsecondofrealtime:
•Timecode:Indicatesthesecti onofthefilemeasured
•Date:Indicatesthecalendardateonwhichthemeasurementwasmade
•Timeofday:Indicatesthetimeofdaythemeasurementwasmade
• Dialoguepresent:Indicatesthechannelsthatcontaineddialogueornodi
alogue
•Themeasurementsyouchose
•Thewarningsyouchose
•Peak(dBFS):Indicatesthelargestpeakvaluemeasuredinthesection
•Peakcount:Indicatesthenumberofpeaksinthesectionthatexceededthepeakcount
thresholdvalue
Thelogalwaysdisplaysmeasurementswiththeprecisionoftenthsofaunit.
5.2 Viewing the Graph
AsshowninFigure 5‐3,DolbyMediaMeter2cangraphuptosixmeasurementsofthe
selectedfile:
•
Infinite Dialogue(withDialogueIntelligenceon)
•
Short Term Dialogue(withDialogueIntelligenceon)
•
Dialogue Range(withDialogueIntelligenceon)
•
Infinite All(withDialogueIntelligenceoff)
•
Short Term All(withDialogueIntelligenceoff)
•
Sample PeakorTrue Peak(dependingonyourconfigurationchoice)
Figure5‐3 
Figure 5-3 Sample Graph
Note: Themeasuredpeakvalueisanoverallpeak,notrelatedtotheselectionof
DialogueIntelligence.
