Upgrading/Installing the DP600 Software
Dolby
®
DP600 Program Optimizer Manual 55
3.3 Upgrading/Installing the DP600 Software
TheDP600packingkitincludesaninstallationDVD.Withthisdisc,youcanperforma
cleaninstallationoranupgradeoftheDP600software(ifrequired).Acleaninstallation
restorestheDP600tothefactorysettings.Anupgradesimplyupdatesthesoftwaretothe
latestrelease,retainingallyourcustomsettings.
Toperformanupgradeoraclean
installationoftheDP600software:
1. ObtaintheDP600DVDfromDolby,andbesuretheprovidedkeyboardisconnected
tooneoftheunit’sUSBports.
2. InserttheDVDintheCD/DVDdrive,andrebootthesystem.
Amessagesaysthatthesoftwareisalready
installedanddisplaysthecurrently
installedversionandtheversionontheDVD.Itpromptsyoutoeithertype
yto
upgradeorpressanykeytostartacleaninstallation.
3. Press
y toupgradeorpressanykeytostartacleaninstallation.
Theupgradeorcleaninstallationprocessbegins.Whenthe newsof twareiscompletely
installed,youareprompted topressanykeytoreboot,andtoremovetheDVD.
4. PressanykeytorebootandremovetheinstallationdiscfromtheCD/DVD
drive.
Whenthesystemreboots,ifthediscisstillintheCD/DVDdrive,acleaninstallation
begins.
YourDP600touchscreenwascalibratedduringthemanufacturingprocess,butyou
mayneedtorecalibratethetouchscreenafteracleaninstallation.WhentheDP600
rebootsafteracleaninstallation,thecalibration
setupappearsonthefront‐paneltouch
screen.Thecalibrationsetupenablesyoutoconfigurethetouchscreen,soitresponds
properly.Tocalibrate thetouchscreen,youneedtoproceedasfollowswithin
approximately30secondsfromthetimeitappears.Ifyoudonotproceedwithinthis
timeperiod,
thecalibrationscreendisappears.
Asmalltargetappearsattheupperleftcornerofthecalibrationsetup,andacross
appearsateachoftheotherthreecorners,asshowninFi gure 3‐16.Tocalibratethe
touchscreen:
•Pressthe targetattheupperleftcornerforacoupleofseconds
untilitchangesto
across.
Thecrossattheupperrightcornerchangestoatarget.
•Pressthe targetattheupperrightcorneruntilitchangestoacross.
• Continuetheaboveprocedureatthelowerleftcornerandthelowerrightcorner.
Whenthecalibrationiscomplete,the
DP600Welcome!screenappears,providing
achecklistofthingsyouneedbeforeyoucanreconfigureyoursystem,asshown
inFigure 2‐3.FollowtheinstructionsinStartingtheSystemfortheFirstTimeon
page 10toreconfigureyoursystem.
Figure3‐16 
Figure 3-16 Calibration Setup Screen
Press target
