Inc. Program Optimizer Manual

Maintaining the DP600 Hard Drives
Dolby
®
DP600 Program Optimizer Manual 45
2. RemovetheDP600front‐paneldrivecoverbyplacingonehandonitsleftsideand
onehandonitsrightside,thenpullingittowardyouuntilitdisengagesfromthe
mainunit,asshowninFigure 3‐2.
Figure3‐2 
Figure 3-2 Removing the DP600 Drive Cover
3. UseaP hillipsscrewdrivertoloosenthefourscrewsthatsecurethedriveretaining
bracket,thenremovethebracketasshowninFigure 3‐3.
Figure3‐3 
Figure 3-3 Remove the Drive Retaining Bracket
Caution: Whenlooseningthescrews,besurenottoremovethemcompletelyfromthe
bracket.
